Product
FAV 38864
/fileadmin/_processed_/csm_T600_FAV3884008_a_e4a2241808.png /fileadmin/user_upload/Product_Database/Bilder/T600_FAV3884008_a.png
/fileadmin/_processed_/csm_T600_FAV3884008_detail1_f1f592447d.png /fileadmin/user_upload/Product_Database/Bilder/T600_FAV3884008_detail1.png
/fileadmin/_processed_/csm_T600_FAV3884008_detail2_347bad2ba7.png /fileadmin/user_upload/Product_Database/Bilder/T600_FAV3884008_detail2.png Abbildung ähnlich
Steel-grid fixed resistor unit, degree of protection IP 20, without weatherproof roof, air outlet on top,
In completely closed zinc sheet enclosure with barrier grid at the bottom and powered ventilation by an integrated ventilator.
With air flow monitoring by wind indicator relay. Ceramic insulated flat or bolt terminals of 35A up to 400A in variable combinations available.
In completely closed zinc sheet enclosure with barrier grid at the bottom and powered ventilation by an integrated ventilator.
With air flow monitoring by wind indicator relay. Ceramic insulated flat or bolt terminals of 35A up to 400A in variable combinations available.
Product group
T600 | Steel-grid Fixed Resistors
Type series
FAV 3
- Data sheet
- Download
Electrical data
Power dissipation
250 kW
Ω value production range
0,39 Ohm - 5,8 Ohm
Degree of protection
IP20
Connection
on terminals inside housing
Voltage range
up to 3 x 500 VAC and derived DC voltages
Options
• with integrated switching devices in an attached switch cabinet for controlling the partial resistors
• with 2 temperature switches wired on terminals
• special voltages for flow fan
• please ask for devices with higher power ratings or other construction forms
• mobile design with rollers
• with 2 temperature switches wired on terminals
• special voltages for flow fan
• please ask for devices with higher power ratings or other construction forms
• mobile design with rollers
Mechanical data
Weight approx.
370 kg
Dimensions
A: 1700 mm
B: 1750 mm
C: 955 mm
D: 850 mm
E: 995 mm
F: 970 mm
B: 1750 mm
C: 955 mm
D: 850 mm
E: 995 mm
F: 970 mm
Application
Mounting
floor-level mounting
Typical application
starting resistor for slip-ring motorsbraking resistor
Dimension drawing
Type series: 16m0182_FAV385-388.pdf
Datenblatt
DE: T600_FAV-FSV.pdf
EN: T600E_FAV-FSV.pdf
Declaration of conformity
28_FAV-M_385-388_EG-Konformitaetserklaerung_DeclarationOfConformity.pdf
Wiring diagram
Not available
3D data
Not available
